[ SPEC MANIFEST ]
[ CORE TELEMETRY ] LIVE FEED
2617 MHz
BOOST CLOCK
8 GB
VIDEO MEMORY
4608
CUDA CORES
180 W
BOARD POWER
[ PARAMETER TABLE ] // 28 PARAMETERS
[ CORE ARCHITECTURE ] SPEC·01
GPU Vendor NVIDIA
Series GeForce RTX 5000
CUDA Cores 4608
Boost Clock 2617 MHz
Factory OC Yes
[ MEMORY ] SPEC·02
Memory (VRAM) 8 GB
Memory Type GDDR7
Memory Bus 128-bit
Memory Bandwidth 448 GB/s
Memory Clock 28000 MHz (28 Gbps effective)
[ THERMAL & POWER ] SPEC·03
Board Power (TDP) 180 W
Min PSU 600 W
Power Connectors 1x 8-pin
Cooling Dual Fan
[ DISPLAY & OUTPUTS ] SPEC·04
Outputs 1x HDMI 2.1b, 3x DisplayPort 2.1b
Max Resolution 7680×4320
Max Monitors 4
DisplayPort 2.1b
[ INTERFACE & FORM ] SPEC·05
Interface PCIe 5.0 x16
Length 204 mm
Slot Width 2.5-slot
Form Factor Full-Height/Half-Length
Dimensions 204 x 117 x 50 mm
[ FEATURES / API ] SPEC·06
DirectX 12 Ultimate
OpenGL 4.6
FreeSync G-SYNC
[ SUPPORT ] SPEC·07
Manufacturer 3 Years Limited MSI → (opens in a new tab)
NIMBUS 1 Year →
