[ SPEC MANIFEST ]
[ CORE TELEMETRY ] LIVE FEED
2542 MHz
BOOST CLOCK
12 GB
VIDEO MEMORY
6144
CUDA CORES
250 W
BOARD POWER
[ PARAMETER TABLE ] // 22 PARAMETERS
[ CORE ARCHITECTURE ] SPEC·01
GPU Vendor NVIDIA
Series GeForce RTX 5000
Process Node TSMC 4N
CUDA Cores 6144
Boost Clock 2542 MHz
[ MEMORY ] SPEC·02
Memory (VRAM) 12 GB
Memory Type GDDR7
Memory Bus 192-bit
Memory Bandwidth 672 GB/s
Memory Clock 28000 MHz (28 Gbps effective)
[ THERMAL & POWER ] SPEC·03
Board Power (TDP) 250 W
Min PSU 650 W
Power Connectors 1x 16-pin
[ DISPLAY & OUTPUTS ] SPEC·04
Outputs 2x HDMI 2.1b, 3x DisplayPort 2.1b
DisplayPort 2.1b
[ INTERFACE & FORM ] SPEC·05
Interface PCIe 5.0 x16
Length 304 mm
Slot Width 2-slot
Dimensions 304.4 x 115.8 x 41.6 mm
[ FEATURES / API ] SPEC·06
DirectX 12 Ultimate
OpenGL 4.6
[ SUPPORT ] SPEC·07
NIMBUS 1 Year →
