Sapphire unit, dual-fan cooling, 2.2-slot, 260 mm long. Rated 230 W; Sapphire recommends a 650 W supply.

NIMBUS COVERAGE
1 Year →
SHIPS FROM
Low Earth Orbit
FREIGHT
Free · contiguous USA
* Verify final terms with the manufacturer — NIMBUS listing may differ

The Sapphire PULSE RX 6700 XT is a 12 GB GDDR6 graphics card built on AMD's RX 6700 XT with 2,560 stream processors, a 2581 MHz boost clock and 4 display outputs over PCIe 4.0.

  • Memory 12 GB GDDR6 · 192-bit bus · 16 Gbps · 384 GB/s bandwidth
  • Cores 2,560 stream processors · DirectX 12 Ultimate
  • Boost 2581 MHz boost · 2321 MHz base · 2424 MHz game
  • Interface PCIe 4.0 x16 · 1x HDMI, 3x DisplayPort at 7680x4320
  • Power 230 W board power · 1x 8-pin + 1x 6-pin · 650 W recommended PSU

Limited manufacturer warranty from Sapphire, plus NIMBUS Cybertech's 1 Year coverage.

Ships from NIMBUS Cybertech, Dallas TX. Free shipping within the contiguous USA.

[ SPEC MANIFEST ]
[ CORE TELEMETRY ] LIVE FEED
2581 MHz
BOOST CLOCK
12 GB
VIDEO MEMORY
2560
STREAM PROCESSORS
230 W
BOARD POWER
[ PARAMETER TABLE ] // 31 PARAMETERS
[ CORE ARCHITECTURE ] SPEC·01
GPU Vendor AMD
Series Radeon RX 6000
Process Node 7nm
Stream Processors 2560
Compute Units 40
Ray Accelerators 40
Infinity Cache 96MB
Boost Clock 2581 MHz
Game Clock 2424 MHz
[ MEMORY ] SPEC·02
Memory (VRAM) 12 GB
Memory Type GDDR6
Memory Bus 192-bit
Memory Bandwidth 384 GB/s
Memory Clock 16000 MHz (16 Gbps effective)
[ THERMAL & POWER ] SPEC·03
Board Power (TDP) 230 W
Min PSU 650 W
Power Connectors 1x 8-pin + 1x 6-pin
Cooling Dual-X, 2 fans
[ DISPLAY & OUTPUTS ] SPEC·04
Outputs 1x HDMI, 3x DisplayPort
Max Resolution 7680×4320
DisplayPort 1.4
[ INTERFACE & FORM ] SPEC·05
Interface PCIe 4.0 x16
Length 260 mm
Slot Width 2.2
Form Factor ATX
Dimensions 260 x 119.85 x 49 mm
[ FEATURES / API ] SPEC·06
DirectX DirectX 12 Ultimate
Vulkan Yes
FreeSync Yes
[ SUPPORT ] SPEC·07
NIMBUS 1 Year →
