[ SPEC MANIFEST ]
[ CORE TELEMETRY ] LIVE FEED
3320 MHz
BOOST CLOCK
16GB
VIDEO MEMORY
2048
SHADER CORES
160W
TOTAL BOARD PWR
[ PARAMETER TABLE ] // 28 PARAMETERS
[ CORE ARCHITECTURE ] SPEC·01
GPU Vendor AMD
Series Radeon RX 9000
Process Node 4nm
Shader Cores 2048
Compute Units 32
Ray Accelerators 32
Infinity Cache 32MB
Boost Clock 3320 MHz
Game Clock 2780 MHz
[ MEMORY ] SPEC·02
Memory (VRAM) 16GB
Memory Type GDDR6
Memory Bus 128-bit
Memory Speed 20 Gbps
[ THERMAL & POWER ] SPEC·03
Board Power (TDP) 160W
Min PSU 450W
Power Connectors 1x 8-pin
Cooling WINDFORCE, 3 fans
[ DISPLAY & OUTPUTS ] SPEC·04
Outputs 1x HDMI, 2x DisplayPort
Max Resolution 7680x4320
DisplayPort 2.1a
[ INTERFACE & FORM ] SPEC·05
Interface PCIe 5.0 x16
Length 281mm
Slot Width 2
Form Factor 2 slot, ATX
Dimensions 281 x 118 x 40 mm
[ FEATURES / API ] SPEC·06
DirectX DirectX 12 Ultimate
Vulkan Yes
FreeSync Yes
