[ SPEC MANIFEST ]
[ CORE TELEMETRY ] LIVE FEED
2920 MHz
BOOST CLOCK
32GB
VIDEO MEMORY
4096
SHADER CORES
300W
TOTAL BOARD PWR
[ PARAMETER TABLE ] // 28 PARAMETERS
[ CORE ARCHITECTURE ] SPEC·01
GPU Vendor AMD
Series Radeon AI PRO
Process Node 4nm
Shader Cores 4096
Compute Units 64
Ray Accelerators 64
Infinity Cache 64MB
Boost Clock 2920 MHz
Game Clock 2350 MHz
[ MEMORY ] SPEC·02
Memory (VRAM) 32GB
Memory Type GDDR6
Memory Bus 256-bit
Memory Speed 20 Gbps
[ THERMAL & POWER ] SPEC·03
Board Power (TDP) 300W
Min PSU 750W
Power Connectors 1x 16-pin
Cooling Blower, 1 fan
[ DISPLAY & OUTPUTS ] SPEC·04
Outputs 1x HDMI, 3x DisplayPort
Max Resolution 7680x4320
DisplayPort 2.1a
[ INTERFACE & FORM ] SPEC·05
Interface PCIe 5.0 x16
Length 267mm
Slot Width 2
Form Factor 2 slot, ATX
Dimensions 267 x 111 x 40 mm
[ FEATURES / API ] SPEC·06
DirectX DirectX 12 Ultimate
Vulkan Yes
FreeSync Yes
